GK-1050T is made on the basis of PVDF surface treatment, another layer of titanium dioxide coating is applied, so that the self-cleaning property of the film material is better and the service life is longer.
Specifications:
Item | Index | Unit | Test Method |
Coating Method | Knife Coating | - | - |
Base Fabric Construction | 100%PET (1300D*1300D 30*32) | D/sq.inch | DIN60001 |
Weight | 1050(+15,-15) | g/sq.m | DIN53352 |
Thickness | 0.81-0.82 | mm | DIN53353 |
Tensile Strength | 5300/5100 | N/5cm | DIN53354 |
Tear Strength | 620/570 | N | DIN53363 |
Adhesive Strength | 130/125 | N/5cm | DIN53357 |
Temperature Resistance | -30 - +70 | °C | DIN EN 1876-2 |
Light Fastness | ≥7 | grade | DIN EN ISo877 |
Flammability | B1 | B1 | DIN 4102 |
Notes: Standard Size 3m width, 100m Length
Usage:
GK-1050T is made on the basis of PVDF surface treatment, another layer of titanium dioxide coating is applied, so that the self-cleaning property of the film material is better and the service life is longer.
Specifications:
Item | Index | Unit | Test Method |
Coating Method | Knife Coating | - | - |
Base Fabric Construction | 100%PET (1300D*1300D 30*32) | D/sq.inch | DIN60001 |
Weight | 1050(+15,-15) | g/sq.m | DIN53352 |
Thickness | 0.81-0.82 | mm | DIN53353 |
Tensile Strength | 5300/5100 | N/5cm | DIN53354 |
Tear Strength | 620/570 | N | DIN53363 |
Adhesive Strength | 130/125 | N/5cm | DIN53357 |
Temperature Resistance | -30 - +70 | °C | DIN EN 1876-2 |
Light Fastness | ≥7 | grade | DIN EN ISo877 |
Flammability | B1 | B1 | DIN 4102 |
Notes: Standard Size 3m width, 100m Length
